Nixie Bargraph Thermometer (Kit | 170589-71)

Nixie Bargraph Thermometer (Kit | 170589-71)

Overview

IN-9 Nixie Bargraph Thermometer kit from Elektor Labs

  • Beautiful graphical representation with Russian IN-9 tube
  • Colour-illuminated scale
  • Based on an Arduino Nano
  • Easy to assemble, only through-hole parts are used

This kit comes unassembled, with all electrical and mechanical parts included. Soldering required.

The Nixie Bargraph Thermometer was described in Elektor Magazine (July & August 2018)

Overview

IN-9 Nixie Bargraph Thermometer kit from Elektor Labs

  • Beautiful graphical representation with Russian IN-9 tube
  • Colour-illuminated scale
  • Based on an Arduino Nano
  • Easy to assemble, only through-hole parts are used

This kit comes unassembled, with all electrical and mechanical parts included. Soldering required.

The Nixie Bargraph Thermometer was described in Elektor Magazine (July & August 2018)

62,96 €
Non membres: Regular Price 69,95 €
En stock
Shipping time: approx. 5 days

Détails

The IN9-Nixie Bargraph Thermometer displays room temperatures on a colour-illuminated scale in Celsius and Fahrenheit.
Various sensors are supported.
All functions are controlled by an Arduino Nano, also the attractive visual effects (bargraph and RGB backlight with adjustable colours).

Main features

  • Temperature scale in Celsius and Fahrenheit from 10°C to 30°C / 50°F to 85°F
  • Graphical representation with Russian IN-9 tube
  • RGB backlight with adjustable colours
  • 5 V DC supply voltage via USB connector
  • Based on an Arduino Nano
  • 0.6 - 1.7 W of energy consumption depending on temperature (+/– 0.9 W at 20°C)
  • Supports temperature sensors DS18B20, DS18S20 and DS1822
  • Uses only through-hole parts
  • Arduino development environment

Kit contains:

  • IN-9 Nixie tube
  • Arduino Nano
  • Transparent laser-cut acryl case
  • 5 V DC power supply
  • all other electrical & mechanical parts


Note: no part of this kit is pre-assembled. Soldering is required. Through-hole parts only (illustrated assembly manual available - PDF)

-Update 2018-05-29: Assembly Manuel v.2

Spécifications

More Information
réf. 18476
marque Elektor Labs
Référence de rédaction 170589
