Build Your Own Software-Defined Radio (E-book)

Description

Practical Guide to Modular RF Design

Build Your Own Software-Defined Radio combines RF circuitry with hardware programming and PC-based signal processing. The e-book presents a modular approach to building a complete SDR system using RF Bricks – from the mechanical framework and RF modules to measurement tools, PC software, and FPGA implementations. Practical explanations guide readers through real signal paths, construction steps, and measurement routines, linking hardware and software into a flexible SDR platform.

Key topics include:

  • Mechanical setup: RF Brick template, chassis, and 19-inch module carrier
  • Bridges: USB isolator, I²C level shifter, I²C power switch, and practical examples
  • Signal-chain design with RF Bricks: antennas, band filters, NanoVNA work, preamplifiers, PLLs, demodulators, direct-conversion chains, multiband options, and narrowband bricks
  • RF measurement Bricks: single- and dual-tone sources, NPR methods, noise generators, notch filters, broadband amplifiers, and impedance bridges
  • Useful accessories: ATU-100 tuner, X-Phase QRM eliminator, and firmware notes
  • PC host software: SoapyAudio adjustments, GQRX, SDR++, and added functionality
  • GnuRadio elements: control blocks, SSB demodulation, GUI components, messaging, and filter handling
  • FPGA-based SDR: VHDL, toolchains, ADC/DAC blocks, oversampling, and a complete SSB/CW signal chain

With its modular structure and detailed working examples, this e-book offers a practical path to building and extending modern SDR systems.


Fiche produit

Practical Guide to Modular RF Design Build Your Own Software-Defined Radio combines RF circuitry with hardware programming and PC-based signal processing.... Lire la suite

€ 32,95 (TVA incluse)
Membres € 26,36

    Détails

    SKU : 21249
    EAN : 9783895767104
    ISBN : 978-3-89576-710-4
    Auteur : Thomas Duden
    Langue : English
    Pages : 328
    Format : PDF

    Description

    Practical Guide to Modular RF Design

    Build Your Own Software-Defined Radio combines RF circuitry with hardware programming and PC-based signal processing. The e-book presents a modular approach to building a complete SDR system using RF Bricks – from the mechanical framework and RF modules to measurement tools, PC software, and FPGA implementations. Practical explanations guide readers through real signal paths, construction steps, and measurement routines, linking hardware and software into a flexible SDR platform.

    Key topics include:

    • Mechanical setup: RF Brick template, chassis, and 19-inch module carrier
    • Bridges: USB isolator, I²C level shifter, I²C power switch, and practical examples
    • Signal-chain design with RF Bricks: antennas, band filters, NanoVNA work, preamplifiers, PLLs, demodulators, direct-conversion chains, multiband options, and narrowband bricks
    • RF measurement Bricks: single- and dual-tone sources, NPR methods, noise generators, notch filters, broadband amplifiers, and impedance bridges
    • Useful accessories: ATU-100 tuner, X-Phase QRM eliminator, and firmware notes
    • PC host software: SoapyAudio adjustments, GQRX, SDR++, and added functionality
    • GnuRadio elements: control blocks, SSB demodulation, GUI components, messaging, and filter handling
    • FPGA-based SDR: VHDL, toolchains, ADC/DAC blocks, oversampling, and a complete SSB/CW signal chain

    With its modular structure and detailed working examples, this e-book offers a practical path to building and extending modern SDR systems.
